en EPSILON SERIES STRAIGHT AXIAL ISO PISTON PUMP
Straight Axial Piston Pumps
EPSILON SERIES STRAIGHT AXIAL ISO PISTON PUMP
Technical Specifications
| Product Code | Displacement (cm3 / rev) | Max. Cont. Pressure (%100) (bar) | Max. Peak. Pressure (6 sec.max.)(bar) | Max. Cont. Speed (rpm) | Inlet | Outlet | Direction | |
|---|---|---|---|---|---|---|---|---|
| 33549020 | 20 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549026 | 26 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549034 | 34 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549042 | 42 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549046 | 46 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549052 | 52 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549055 | 55 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional | |
| 33549060 | 60 | 270 | 350 | 1000 | 1 1/2" | 3/4" | Bi-Directional |
