30 SERIES NH GEAR PUMP
Technical Specifications
| Product Code | Displacement (cm3 / rev) | Max. Cont. Pressure (%100) (bar) | Max. Peak. Pressure (6 sec.max.)(bar) | Max. Cont. Speed (rpm) | Inlet | Outlet | Direction | |
|---|---|---|---|---|---|---|---|---|
| 22277017 | 17 | 300 | 320 | 2600 | G1/2" | G1/2" | CCW Left | |
| 22278017 | 17 | 300 | 320 | 2600 | G1/2" | G1/2" | CW Right | |
| 22279017 | 17 | 300 | 320 | 2600 | G1/2" | G1/2" | Bi-Directional | |
| 22277027 | 27 | 290 | 310 | 2600 | G3/4" | G1/2" | CCW Left | |
| 22278027 | 27 | 290 | 310 | 2600 | G3/4" | G1/2" | CW Right | |
| 22279027 | 27 | 290 | 310 | 2600 | G3/4" | G1/2" | Bi-Directional | |
| 22277034 | 34 | 285 | 305 | 2300 | G3/4" | G3/4" | CCW Left | |
| 22278034 | 34 | 285 | 305 | 2300 | G3/4" | G3/4" | CW Right | |
| 22279034 | 34 | 285 | 305 | 2300 | G3/4" | G3/4" | Bi-Directional | |
| 22277043 | 43 | 280 | 300 | 2100 | G3/4" | G3/4" | CCW Left | |
| 22278043 | 43 | 280 | 300 | 2100 | G3/4" | G3/4" | CW Right | |
| 22279043 | 43 | 280 | 300 | 2100 | G3/4" | G3/4" | Bi-Directional | |
| 22277051 | 51 | 230 | 280 | 2100 | G1" | G3/4" | CCW Left | |
| 22278051 | 51 | 230 | 280 | 2100 | G1" | G3/4" | CW Right | |
| 22279051 | 51 | 230 | 280 | 2100 | G1" | G3/4" | Bi-Directional | |
| 22277061 | 61 | 225 | 260 | 2000 | G1" | G3/4" | CCW Left | |
| 22278061 | 61 | 225 | 260 | 2000 | G1" | G3/4" | CW Right | |
| 22279061 | 61 | 225 | 260 | 2000 | G1" | G3/4" | Bi-Directional | |
| 22277082 | 82 | 200 | 220 | 1700 | G1 1/4" | G1" or G3/4" | CCW Left | |
| 22278082 | 82 | 200 | 220 | 1700 | G1 1/4" | G1" or G3/4" | CW Right | |
| 22279082 | 82 | 200 | 220 | 1700 | G1 1/4" | G1" or G3/4" | Bi-Directional | |
| 22277100 | 100 | 190 | 220 | 1600 | G1 1/4" | G1" or G3/4" | CCW Left | |
| 22278100 | 100 | 190 | 220 | 1600 | G1 1/4" | G1" or G3/4" | CW Right | |
| 22279100 | 100 | 190 | 220 | 1600 | G1 1/4" | G1" or G3/4" | Bi-Directional | |
| 22277125 | 125 | 170 | 200 | 1600 | G1 1/4" | G1" or G3/4" | CCW Left | |
| 22278125 | 125 | 170 | 200 | 1600 | G1 1/4" | G1" or G3/4" | CW Right | |
| 22279125 | 125 | 170 | 200 | 1600 | G1 1/4" | G1" or G3/4" | Bi-Directional |
